Specifications:
input: 0-1 vdc, proximity (pnp type)
digital inputs: two (potential free contacts)
display: 14 digit 7-segment 0.56” red led display organised in three groups.
aggregate rate (tons/hour) : 4 digits
conveyor speed (meter/sec) : 3 digits
total aggregate (tons) : 8 digits
non-resettable eight digit totaliser (reset possible only thro’ password)
keypad: eight keys membrane keypad
discrete leds: two
power supply: 230v +/- 10% ac
proximity power supply: +24v dc/50 ma
output options: 0 to 10 v dc
relay: one for alarm condition
serial interface: rs232 or rs485 (optional)
scaling method: linear (multiplying factors: programmable)
warm up time: 10 minutes
accuracy: 0.1% of fs +/- 1 digit
enclosure: metalised din standard, panel mounting type
dimensions: outer: 144 mm x 144 mm x 120 mm
panel cutout: 138 mm x 138 mm
weight: approx. 2 kgs
