Contact SupplierWe are offering jcjx-3000a5000a8000a copper coating machine (production line machine)
main usage:the copper wire can be coated a layer of steel outside
main feature:
1.double floor water tank, save space.
2.six rollers, the whole rack made of stainless steel.
3.main motor by frequency control.
4.take-up part controlled by torque motor, stable tension.
Technical parameter:
machine model
jcjx-3000a
jcjx-5000a
jcjx-8000a
control system
button type
main power control
controlled by electric motor
take-up power control
controlled by torque motor
wire diameter
1.01.4mm
1.201.80mm
1.22.2mm
main motor
2.2kw
3.3 4kw
4kw 5.5kw
take-up motor
ylj112-12
ylj112-12
ylj132-16
spool reel size
300mm 400mm or according to customers requirement
take-up type
shaftless take-up mc
traversing type
plam shaft type
transmission type
tri-angle belt, chain
line speed
10mmin 120mmin
rectifier
3000a
5000a
8000a
dimension(mm)
15000*1200*1400
18000*1600*1600
20000*1800*1600
weight
3500kg
5000kg
6000kg
