Contact SupplierWe are offering Copper Plating Machine.
main parameters:
cathode swing angle 15°, 15 times /minute
filter 3~5 tanks times / hours
temperature tolerance ±1℃
min hole diameter φ0.20
vibration mode batch-type
protector anti-collision,anti-dry heating device
electroplating uniformity in deep tank ±20%
electroplating uniformity in shallow tank ±10%
features:
adopted plc and touch screen control system.
The oscillatory angle of cathode is 15º and the chemical tanks configurate with motor vibrator and pneumatic vibrator alternatively,that is improved the hole of pcb in plating process.
Imported brake deceleration motor for driving transmission,operation is smooth and reliable.
The de-smear tank with regeneration system that can increase efficiency and reduced the cost.
The concentration of air exhaust and drainage, make appearance more clean and easy to installation.
Appearance is adopt pp materials ,have good weather-resist and water resist.
