Copper Wire Recycling Machine, Brand Name : AZS

We are offering waste copper wire recycling/separating machine/equipment.
Scrap copper wire machine
output:300-400kgh
copper purity:99.99%
13 year's experiences
no water,no dust pollution
600 ce scrap copper wire machine copper wire recycling machine
this scrap copper wire machine copper wire recycling machine is specialized in recycling telephone wires, computer wires, automobile wires, tele-communication cables, etc, combines many processions into one, including crushing, conveying, dust collecting, separating process, the whole process is controlled by plc. It can recycle both copper and pvc plastic,have high economic benefit, without environmental pollution .
Scrap copper wire machine copper wire recycling machine features:
1.with ce certificate;
2.with latest technology and unique design,which has greatly better effect than the old model azs918-600;
3.the material of the waste wire can be telephone wire, household electric wire, automotive wire and cables,diameter should be within 25 mm. Just needing 1-2 workers to operate, labour-saving, low investment.
4.has a high recycling rate of 99.99%, when processing the scrapwaste copper wirecables, no need water during the whole process, no dust, no environmental pollution .
5.equipped with plc control system
6.voltage can be changed according to your needs.
scrap copper wire machine copper wire recycling machine technical parameters:
model
item azs-600
power 32.8kw
capacity 300-400kgh
dimension l2830×w2000×h2800mm
weight 2800kg
packing dimension l2900×w2100×h2000mm
packing weight 2900kg
copper wire crusher aluminum copper scrap recycling plant power details:
number item quantity power
1 model 600 crusher 1 set 22kw
2 feeding blower 1 set 2.2kw
3 bottom blower 1 set 3kw
4 suction fan1 1 set 4kw
5 vibratory motor 1 set 0.5kw
6 suction fan2 1 set 1.1kw
total power
32.8kw
scrap copper wire machine copper wire recycling machine process flow chart:
1.crushing process
put waste copper cable into crusher to make plastic skin and copper separate completely
2. Conveying and dust-collecting
after crushing, the crushed material (mixture of copper and plastic) will be conveyed to the separator, during which procedure the plastic granules (including fiber, rope ) are cleaned by the dust cleaner.
3. Separating process
the vibrating separator consists of separating board, amplitude adjustable device, and speed adjustable motor,etc. It is used to separate plastic and copper.
4. Copper-collecting and copper clad recrushing
there are two discharging holes respectively for copper and plastic, if there are any copper clad, they need to be recrushed.
5. All the units are installed on the underbed to form a whole plant, very easy for transport. The machine is well adjusted before shipping, so the customer only needs to connect it to the power supply before production.
