Core Drilling Machine

Description and Specification for Lab Tenders

Core Drilling Machine.
Technical Description »  Heavy duty, Pillar type frame with 2 HP, single phase, AC motor. »  Varying Cutting feeds provided with water-fed swivel head which can be connected to suitable water supply. Provision at base for water collection/drainage. »  Core Preparation from regular and irregular samples Core Size : EX to NX »  Clamping arrangement to hold specimens with regular/irregular shapes to the base of machine. »  Four cutting speeds of 600, 800, 1100 and 1500 rpm. Following Core Bits are available as options: Core Drilling Bit, 21.46 mm dia (EX size)  Core Drilling Bit, 30.10 mm dia (AX size)  Core Drilling Bit, 38 mm dia  Core Drilling Bit, 42.04 mm dia (BX size)  Core Drilling Bit, 54.74 mm dia (NX size) mechanical lab equipments manufacturers
