GENERAL INFORMATION
Order Code
LT-50W -(ElectraMODEL)
Make
Lightronix Technology
Country of Origin
INDIA
Lighting Source & Type
SMD 3030 LED
Number of LED
24
OPTICAL PARAMETERS
Led Beam Angle
90 Degree
CRI (Color Rendering Index)
>80
LED Life Span
>60000 Hours
Color
White/Warm White/Cool White (As Per Order)
Color Temperature
2700-6500K(As Per Order)
Led Voltage/Current
6.2V/150mA
LED Make
Seoul/Bridge lux/Cree/Nichia/Osram (As per Requirement)
Optical Lens
Yes
Luminous Efficiency
140 Lm/W
Total Lumens
3360(±5%)
Optical Efficiency
>93%
Thermal Efficiency
>90%
ELECTRICAL PARAMETERS
Wide Input Voltage Range
90-310VAC(With Auto Cutoff)
Operating Frequency
50/60HZ
Power Consumption
24 Watt
Power Factor
>0.95
THD
90%
Supply Phase
Single Phase Supply
Over voltage Protection
440VAC Protection
Under voltage Protection
90VAC
Auto cutoff Voltage
Lower Side310VAC
PCB INFORMATION
PCB Thickness
1.6mm(±5% Tolerance)
PCB Material
Pure Aluminum-Copper
Copper Layer Thickness
Standard 0.35 Micron
Copper Conductivity
>1 Watt
PCB Size
110x60 mm
MECHANICAL PARAMETERS
Housing Material
Aluminum Pressure Die Casting
Housing Color Type
Metal Powder Coated
Housing Shape
Rectangle
Total Luminaries Weight
0.440 Kg
Luminaries Size
280 ×108 × 50mm3
Pole Dia Entry
45mm
Mounting Device
Clamp
Mounting Style
Pole/Wall
Glass Type
Poly carbonate lens
Cable Entry Option
PG7 Cable Gland with Rubber Washer
Screw Type
Stainless Steel Screw
Gasket Type
Silicone Rubber Gasket
IP Rating
IP65/IP66
Impact Rating
IK08/IK10
Marking Type
