Counter Flow Heat Exchanger

We offer counter flow heat exchanger.
System feature
compact, comprehensive, sturdy design
fully instrumentation for experimentation of heat transfer process study
direct reading of temperature, voltmeter and ammeter measurement.
Demonstrations of heat transfer through concentric tube heat exchanger.
Fault trainer as optional attachments
system description
the apparatus consist of a heat exchanger mounted on a rigid ms structure frame with a control panel. A centrifugal pump and a sump tank made up of non-corrosive pvc are placed at bottom. A separate hot water boiler is supplied with the equipment. It is fitted with a level switch, relief valve. Hot water from the boiler is fed into one end of the inner tube, which gets cools after passing through the length of the tube. Cold water is circulated through the boiler tubes with the help of centrifugal pump.
