Cut To Length Line

Cut To Length Line

Manufacturer and Exporter of Cut To Length Line, Fully Automatic Cut To Length Line, Cut To Length Lines, Cut To Length Machine, NC Servo High Cut To Length Line.

Cut To Length Line are available in a wide range based on sheet thickness to meet the demands of our customers. By offering the qualitative range, we promise to provide best solutions for clients demand. Our product found application in various recognized metal cutting industries.

Details of CTL Line Machines

Coil Car/ Coil Lifter

Coil Car/ Lifter ease the work of loading the coil on De-coiler's Jaws by coinciding the axis of both. Coil Car is power driven and can move to & fro the De-coiler on rails. Coil Car & Coil Lifter both can move up/down by hydraulic cylinder.

De-coiler/Un-coiler Unit

The de-coiler/uncoiling unit of our cut to length line allows several coil stocks to be pre-placed on the loading station. It is available with single head or double heads to suit different requirements.

Snubber & Pillar Table Assembly

Snubber is used for pressing the coil O.D. Snubber can be operated either hydraulically or pneumatically. Hydraulically operated pillar table facilitates the entry of sheet into straightener.

Sheet Leveler

The leveler of our cut to length line may have various designs, from 2HI/4HI/6HI. The rolls can be adjusted manually, hydraulically or by motor. Roll is hardened to HRC 55-60. It provides good abrasion resistance and long service life.
