Cutting Machine C22 Single Phase / Three Phase

Electric motor (Single Phase / Three Phase) KW 1,5 / HP 2 - Self Breaking
Bending Speed (RPM) 98
Weight (kg) 120
Dimensions (cm) 70 / 40 / h 70
Cutting Capability:
Capacity Mild / High Tensile Steel R = 65 kg. / mm²
Number of bars 1 Bar diameters 20
Number of bars 2 Bar diameters 14
Number of bars 3 Bar diameters 8
Capacity Mild / High Tensile Steel R = 85 kg. / mm²
Number of bars 1 Bar diameters 18
Number of bars 2 Bar diameters 12
Number of bars 3 Bar diameters 6
Standard Equipment
- Mechanical Lever Control
- Electric Pedal with Column for remote control
- Screw locator
- Automatic lubrication pump
- Electric panel in metallic box
Technical Features
- Machine with two reductions to increase the cutting strength with less energy consumption;
- Gears and pinions in hardened and tempered steel
- Machine structure in heavy laminate
- Electric panel with coupling through electric pedal and mechanical lever, all included in the price
- Interchangeable blades with 8 cut edges
Light and practical!
Characteristics of cutting machines Atlas Machinery:
►Strong and compact design. Light weight. Frame and reduction unit are in heavy steel plate & castings
►Quick Change Blades: Blades are multi-faced, quickly and easily changed
►Controls: Shear actuation is via foot pedal and/or manual lever
►Easily movable thanks two mounted wheels and retractable tow bar. Mobility!
►In the mobile cover has been incorporated limit switch, so when the cover is raised cutting is impossible, in this way increasing safety
►The gears made of special hardened steel work in the “oil bath”.
►Thermal switch protects electrical components and engine against damage.
►Rotating roll make easy to work with bar.
►Electrical System: equipped with a magnetic motor cut-out and overload protection
►Safety Protection: top shield covers blades with limit switch, anti-repeat lock
