ApplicationUnique input and output sound effects; pass alert blinkers; optional body colors.
SystemIt has been designed with a microprocessor control.It has bidirectional operation. It has a data output on the pass direction. This output can be either a digital output or be directly sent to a PC when controlled by a PC.
ApplicationUnique input and output sound effects; pass alert blinkers; optional body colors.
Power Consumption60 Watt
Length of Arm750, 900 mm or intermediate lengths
ExtrasRequired feed tension conditions may be provided depending on customer requirements.Optional features are available with the system. Custom solutions may be produced.
Technical ServiceFast and uninterrupted high-quality, expert technical support throughout Turkey, Turkish Republic of Northern Cyprus, Central Asia and Balkans.
Sensor ControlÂ
Access ControlÂ
Power Input100 - 240 V AC
Smart ArmThe tourniquet may feel any objects it touches during its back and forth movements and react accordingly.
Emergency ModeControl opportunity linking to security systems (automatic free pass mode in emergency situations, and fire alarms) is available. Emergency passes can also be made by remote control. This way, the tourniquets allows for emergency exits.
Quality StandardsTSEK, ISO 9001:2008
Remote ControlIt may be controlled by button (30 m) or keyless (3 m) remote controls. Thanks to the keyless command module attached to the key holder or that the personnel will keep with them, when one approaches 3 meters to the tourniquet, the tourniquet recognizes th
Button ControlAlso works with a single or double button control. In single button control, tourniquet will make its subsequent movement (closes if open, opens if closed) every time the button is pressed. In double button control, there are separate buttons for opening
Dimensions940 x 200 x 260 mm
Warranty2 years
Body1,2 mm, 304 quality stainless steel
ControlFor pass triggering, it may be used by dry contact or 3-50 V dc impact, or by direct PC control with TTL, CMOS or RS232-RS422-485 can be used. Tourniquet as much as 32 and multiples can be controlled through a single PC. All sorts of access control units
Time ControlIf you wish the tourniquet to close automatically some time after opening, it has a time control adjustable to the desired time.
SystemIt has been designed with a microprocessor control.It has bidirectional operation. It has a data output on the pass direction. This output can be either a digital output or be directly sent to a PC when controlled by a PC.
Operational Temparature1(-20), (+50) C
