Cys Centrifugal Oil Separation Machine, Brand Name : TOP

We are offering Cys Centrifugal Oil Separation Machine.
This centrifuge oil purifier oil separator equipment utilized the high-speed rotation of the centrifugal head to separate the oil, water and impurity from the waste lubrication oil, especially the iron, carbon, oil loam were rotated out up by the high-speed rotation. It applys to power plant, shipping and the lubrication oil, diesel engine oil’s purification of the big machinery equipment.
Main feature:
1. The centrifugal force was produced by the flotation speed above 6000rpm’s oil purifier equipment is 2000 times of the gravity so only 1μm also could be take out which could make the clearance of the oil meet NASS level.
2. It installed the heater and temperature control system which could reduce the viscosity of the oil and the combining power of the oil and water when the temperature was improve certain degree and could improve the efficiency of separated oil and water.
3. Small cubage, large treatment capacity, easy operation and also could be use by movealbe.
4. It is very safety and stable when equipment starts, stops or high-speed rotation; it installed electromagnetic valve for inlet opening, it could cut off the inlet automatically when the power being short of un-normally.
Apply to oils
Cut oil, hydraulic oil, engine oil, cycle oil, fire-fight oil, forging oil, lubrication oil, drawing the line oil, anti-rust oil, ship oil ect.
Technical parameter
Model Capacity
(Lh) Drum Diameter(mm) Rotation Speed(rmin) Motor(Kw) Discharge mode Separator
Factor Weight(kg) Size
mmxmmxmm
CYS-1 1500 230 6930 2.2 Manual 6170 245 850x625x985
CYS-2 2000 270 7200 4 Automatic 6950 550 865x645x1100
CYS-3 3000 315 6500 5.5 Automatic 7000 650 900x600x1150
CYS-4 4000 385 6500 7.5 Automatic 7500 750 1100x1050x1250
CYS-5 5000 430 6000 11 Automatic 8050 900 1200x950x1400
CYS-6 10000 500 5500 18.5 Automatic 8000 1200 1250x1000x1550
