CZL601AC Elecrtric Aluminium CZL-601AC Load Cell, for Industrial Use

Listing ID #828899

190 - 250 / piece

Get Latest Price

MOQ 10 Piece
Country of OriginIndia
TypeLoad Cell
MaterialAluminium
ApplicationIndustrial Use
Supply Type Manufacturer, Exporter, Retailer, Importer

Preferred Buyer From : All over the world

View More Details

Send Enquiry

Product Details

Country of Origin India
Type Load Cell
Material Aluminium
Application Industrial Use
Power Source Elecrtric
Temperature 45-50deg C
Brand Name CZL601AC

Rated Load (Kg) : 80, 100, 120, 150, 200 With our deep commitment, we have established ourselves as a reliable Exporter, Importer and Supplier of Load Cell CZL-601AC. Load Cell (CZL-601AC), which we offer is made of alloy aluminum, hermetically sealed with glue to IP65. The surface of Load Cell (CZL-601AC) is anodized and protected against corrosion. Load Cell (CZL-601AC) is generally used in electronic table top scale, floor scale and other weighing equipment.

Standard Specification

Nominal output	2.0 + 0.1 mV/v (mili volt per volt)
Precision	C2 / C3 (0.017% & 0.02% FSO comprehensive error)
Excitation voltage	9 VDC – Maximum 12 VDC
Platter size	400mm x 400mm
Safe load	120% of Rated capacity
Ultimate Load	150% of Rated Capacity
Non Linearity	<+0.03% of FSO (Full Scale Output)
Creep (30 minutes)	<+0.025% of FSO
Zero Balance	< +1% of FSO
Input Resistance	400 + 10 ohms
Output Resistance	350 + 5 ohms
Insulation Resistance	Above 5000 Mega ohms
Temp. Compensation	- 10 ^ºC to + 40^ºC
Temp. Effect on Zero & span	<0.03% FSO / 10^ºC
Material	Alluminium alloy, colourless anodized
Cable	4mm, 2mts

Installation Size (mm)

Download Detail File : Click Here

Wiring Schematic Diagram

Red : Input (＋)
White : Output (－)
Black : Input (－)
Green : Output (＋)

Notes：It used 4-core shielded cable(φ5×3000mm)

Load Instruction

Download Detail File : Click Here

Additional Information

Delivery Time 1 Working Day
