D.C. Motor Controller

We manufacture D.C. Motor Controller that is specially designed to provide a speed adjustment ranging from zero to full rated speed. Our D.C. Motor Controller functions with D.C. Motors Shunts or compound type through supplying two rectified main supplies to field circuit and armature. The supply of field is carried to ZZ(±) and Z(-) which is at fixed voltage. Afterwards, the armature supply is carried out both the terminals A and AA. This supply varies from 0-80% from the supreme supply voltage through the means of wave controlled system. The SCR’s (Thyristors) is fired by a trigger circuit controlled by a superior quality amplifier. This amplifier works from a small D.C. voltage input. As the result, the speed of the motor remains constant.
Salient Features
Our D.C. Motor Controllers are grounded on the basis of Thytristors (SCR) having conduction angle managed by completely encapsulated trigger circuits that deliver wave rectification on Armature and Field.Light in weight and easy to maintain transformersTechnically advanced Field Rectifier, SCR, DIODE Unit and Triggering CircuitTerminals are fixed on the lower portion of the rackConsist of current limiting circuits that ensure protection to silicon devicesHave high rupturing capacity fuses thereby ensuring prevention from short circuit conditionsArmature Circuit with interlocking system
Capacities Available
Single Phase : 1, 2, 3, 5, 10, 15 H.P. and above.Three Phase : 5, 7, 5, 10, 15, 20, 25, 50, 75, 100, 150, 200, 250, 350, 500 H.P. & above
Speed Regulation
Feedback systems are standardAccuracy 1% of +10% mains voltage variationArmature IR CompensationTachometer GeneratorArmature voltage
D.C. Output Voltages
Armature
180 Volts D.C. variables from zero in Single phase360 Volts D.C. variables from zero in three phase.
Field
200 Volts D.C. fixed. / 400 Volts D.C.
Standard Models Available
Forward and stop push buttons with no volt releaseForward stop and reveres push buttonsForward and stop push buttons plus dynamic braking
Applications
Sugar MillsCoil winding machinesRotary Printing MachinesTextileCementSteel Plants
