1-1 Rated Voltage 48 VDC
1-2 Operating Voltage 36~57 VDC
1-3 Low-Start Voltage 30VDC
1-4 Rated Speed 2750RPM
1-5 Input Current 1.1A
1-6 Input Power 53W
1-7 Air Flow 677CFM 1150m3H
1-8 Static Pressure 0.94inH2O 236Pa
1-9 Acoustical Noise 60 dB(A)
1-10 Life Expectance 50,000Hours(L10)
At 40℃ room, humidity 15%~65%RH.
1-11 Direction of Rotation clockwise
seen on motor
1-12 Direction of Air Flow axial
1-13 Insulation Class Class B
1-14 Insulation Resistance 50 Mega Ohm minimum at 500VDC
Between frame and (+) terminal
1-15 Motor Protection Locked rotor protection
Polarity protection
Automatic restart capability
1-16 Speed Control Control input 0~10VDC PWM
1-17 Protection Type IP44
1-18 Dielectric Strength 10mA maximum at 1000VAC 50Hz five second
Between frame and (+) terminal
1-19 Signal Output FG (Frequency Generator)
