Contact SupplierFeatures
monitor rma volts, amps, cumulative kwh, kilo watts, watt-hours
individual socket monitoring and switching
remote access rs485 modbus via rj45 connection port
sequential power on/shutdown
15a commando plug
lcd display option
specifications
material: powder coated mild steel
connectivity: eia rs232 or rs485 modbus via rj45 connection port
rated voltage: 60vdc (36vdc)
rated current: up to 400a
operating temperature: 5 to +30 degrees celcius
measuring accuracy: +/-2%, [kwh to bs en. 61036:1997] class 2 measuring instrument
display resolution: 0.1 volt, 0.01 amp, 0.1kwh (local display option)
sockets outlets rated current: 15 amps
network connection capacity: 1200 vdc, 1 minute
standard warranty
1 year repair or replace
