We have a well-maintained and spacious storage space and thus, we are flexible enough of meeting the urgent needs. Furthermore, we by no means go out of stock and thus we maintain year round accessibility of all the products. To avoid any type of mechanical and biochemical harms, we pack our products in high-grade packing items that are sturdy as well. Moreover, we provide product details on it as well.
Typical Applications :
| Number of stages | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|
| Reduction ratio | 44.75 | 161922.5 | 647690107 | 256304361 428509 | 102412161444 171420362418 |
| Gearbox length “L”mm | 12.2 | 15.8 | 19.4 | 23 | 26.6 |
| Breaking torque(kgf.cm) | 2 | 3 | 4 | 5 | 5 |
| Gearbox efficiency | 90.00% | 81.00% | 73.00% | 65.00% | 59.00% |
| Motor model | Rated Volt. | No load | Load | Stall | |||||
| Current | Speed | Current | Speed | Torque | Output power | Torque | Current | ||
| V | mA | r/min | mA | r/min | gf.cm | W | gf.cm | mA | |
| DS-250-012-10500 | 12 | ≤180 | 10500 | ≤750 | 8950 | 49 | 4.5 | ≥250 | ≥2600 |
| DS-250-024-16000 | 24 | ≤160 | 16000 | ≤680 | 14160 | 60 | 8.7 | ≥390 | ≥3100 |
| Motor model | Rated Volt. | No load | Load | Stall | |||||
| Current | Speed | Current | Speed | Torque | Output power | Torque | Current | ||
| V | A | r/min | A | r/min | kgf.cm | W | kgf.cm | A | |
| DS-22RP2500126000-19K | 12 | 0.127 | 311.1 | 0.428 | 230.9 | 0.9 | 2.118 | 3.5 | 1.294 |
| DS-22RP25002416000-64K | 24 | 0.139 | 257.2 | 0.661 | 215.7 | 3 | 6.837 | 19 | 3.368 |
