Diagnostic Tools

We are offering diagnostic tools ● functions:
● read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database)
● clear trouble codes and turn off the mil ("check engine" light)
● display current sensor data, including
● engine rpm
● calculated load value
● coolant temperature
● fuel system status
● vehicle speed
● short term fuel trim
● long term fuel trim
● intake manifold pressure
● timing advance
● intake air temperature
● air flow rate
● absolute throttle position
● oxygen sensor voltagesassociated short term fuel trims
● fuel system status
● fuel pressure
● many others
● features:
obd scan is the newly developed wireless scan tool. It supports all obd-ii protocols
automatic
● sae j1850 pwm(41.6kbaud)
● sae j1850 vpw(10.4kbaud)
● iso9141-2(5 baud init,10.4kbaud)
● iso14230-4 kwp(5 baud init,10.4 kbaud)
● iso14230-4 kwp(fast init,10.4 kbaud)
● iso15765-4 can(11bit id,500 kbaud)
● iso15765-4 can(29bit id,500 kbaud)
● iso15765-4 can(11bit id,250 kbaud)
● iso15765-4 can(29bit id,250 kbaud)
● a.sae j1939 can(29bit id,250*kbaud)
● b.user1 can(11*bit id,125*kbaud)
● c.user2 can(11*bit id,50*kbaud)
● default settings(user adjustable)
output protocol: rs232 to bluetooth
frequancy: 38400
voltage: 12v
current: 45ma
bluetooth: 10m
supported platform: andriod, symbian, windows mobile, palm, pc, pocket pc.
