3000/3600rpm Wonyong single phase 20kw Diesel Generator Set

We are offering diesel generator set. Diesel generator set with wheels
1top quality with competitive factory price.
2air-cooled,single phase generator set
3 silent type,1 year warranty
4,2kva,3kva,kva small air-cooled diesel generator are availble.
diesel generator specification
model wy3500a
generating frequency 50 hz 60 hz
max. Ac output 3.3kva 3.2kva
rated ac output 3kva 3.5kva
phase single phase
insulation f
rated ac voltage 220
engine model wy178fa
engine type air cooled,4 stroke,single cylinder
max power output 4hp
displacement 306cc
compressin ratio 2.0: 1
engine speed 3000rpm 3600rpm
starting system recoil /electric
fuel tank capacity 14l
noise level(at 7m) 74db(open type)
pack n.w/g.w 70/77
dimension(mm) 697x475x552
generator set
1.the box is totally closed system, and it`s rainproof ,dustproof,heat insulation and fireproof. It`s been prolessed for noise abatement.heatpnof and heat insulation after processing, the noiseã¢ï¿½â¤75db(a) on a distance of 1 meter.
2.all arrangement of wires are reeved thongh the inflaming retarding . All the cables are inflaming retarding
3.there is a under carrige oil tank in the bottom of the box.there are oil filler pipes for normal and oil pump . It`s capality can remain ten hours at full load,there are fuel level gauge . And high-low fuel level at alarm light
4.design operation conditions
the box must be assembled on smooth substance ground. it must be higher than other grounds. against water flording other people approaching. Environment must be clearing. If conditions can`t reach, it must be point out befor singing a contract.
5.the design conditions are satisfied for the requirement of discharge and dissipating heat system.
6.pressure of discharge system is lower than requirement of normal using. When adding the second discharge and oferation.
7.other requirement:
a. The door is designed easily for daily maintenance and operation.
b. The drain system must be set easily for daily maintenance .
c. Ground connection: leave 2 lead wire for ground connection.
d. Enougn spale for operation
e. Lifetime beyond ten years
8. Technology craft: surface must be smooth. Spray average and no broken.display equipment. Lightswitches must be set stracture advisability and beautiful.
9. Strueture craft: sections are cired up in orden. Sockets are firmed strongly . Safety and easily for maintenance could be shocking proof and enough for transport and harg.
10. Installation: shocking proof sockets. The diameter of copper crew for ground connectionã¢ï¿½â¥m8.
11. The sign must be clear and flat .the package is according to the correlated gb3873
