Contact SupplierWe are offering digital micro hardness tester etc. Digital micro hardness tester with following specification
test load: 0.098n (10gf), 0.246n (25gf), 0.49n (50gf), 0.98n (100gf), 1.96n (200gf), 2.94n (300gf), 4.90n (500gf), 9.80n (1000gf)
leus/indenter switch: with hand turret
carriage control: automatic loading and unloading method
magnification of microscope: for measurement: 400x (object lens 40x, eyepiece 10x)
for observation: 200x (object lens 20x, eyepiece 10x)
load holding time: 5-60 second
measuring microscope: min measuring unit: 0.0625um
testing field: 1-2967hv
micro test table: dimensions 100x100mm
movement: 25mm in x&y axis
max. Height of specimen: 70mm; max. Depth of specimen: 95mm
power supply: ac110v/220v 60/50hz
dimensions: (l ) 425 x (w) 245x (h)490mm;
gross weight: 42kg,
net weight: 35kg
