DMP 10-40 Series - Coating Thickness Gauge - DFT Meter

THE NEW DMP SERIES

Experience the next level of tactile coating measurement

Gauge family for measuring coating thickness.

TOUGHER THAN THE CIRCUMSTANCES. MORE PRECISE THAN THE REST.

The new DMP series sets the standard for tactile and non-destructive coating thickness measurement of magnetized and non-magnetized base materials. The robust and modern design, optimized functionalities, digital probes, and intuitive Tactile Suite software make these compact handheld devices your perfect companions for any measuring requirement.

-Built to last: Next level quality and durability thanks to all-aluminum housing.

-Full measuring control: Feedback via light, sound and vibration whether measured values are within tolerance

-Digital probes: Fully digitized probes for the most demanding measurement tasks.

The all-around capabilities of coating thickness

measurement

Burnished rails

Features

∙ Universal device series for tactile coating thickness

measurement thanks to enormously wide probe

portfolio

∙ Test method: Magnetic induction and amplitude-sensitive eddy current method

∙ Measured value memory: DMP10/20: 10,000 in one

batch, DMP30/40: 250,000 in 2,500 batches

∙ Measurement range: Depending on the combination

of coating and base material and the used probe

∙ Robust aluminium housing with protection class IP64

∙ Replaceable Li-Ion battery for >24h operating time

∙ Easy data transfer via USB-C and Bluetooth

∙ Limit monitoring via light, sound and vibration

∙ Digital and analog probe
