Contact SupplierDMX over ethernet 20Channels Artnet dmx controller Description DMX over ethernet 20Channels Artnet dmx controller is a 20 universe Ethernet to DMX gateway device using Art-Net protocol. Each universe can run up to 512 DMX channel. Suitable for low to mid size matrix and large installation requires multiple DMX universe. Output AC90-240V, Input AC90-240V Support all of country Any country Plug avalible. Our ArtNetDMX controller are available in versions of 3-pin and 5-pin XL connector,to avoid the trouble of using 3-to-5 adapter, please make it clear when placing the order prefer 3pin or 5pin, default is 3pin if customer do not declare. Parameters of DMX over ethernet 20Channels Artnet dmx controller Standard controller can set the IP address and controller name via Artnet setting software Model LED-ANC8x512 LED-ANC16x512 Universe 8 16 Working Voltage AC 110 -240V Output Protocol DMX512 Output connector 35 pin  female Support software Madrix, SUNLITE, Arkaos, Martin, Avolite Input Protocol ART-NET II, ART-NET III EthernetArt-Net RJ45, 10100Mbits Working temperature -20℃-+50℃ Working Environment IP20,Indoor use only Dimension 483x155x44 mm 483x155x88 mm Net Weight 0.9KG 1.86KG Lightning controller can set the IP address and controller name via web Model Lightning 1 Lightning 4 Light
