Contact SupplierImage Sensor |
1/3" Sony CCD | |
Effective Pixels | PAL: 512(H) * 582(V), NTSC: 512(H) * 492(V) | |
Sensing Area | 4.9x3.7mm | |
Horizontal Resolution | 420TV Lines | |
Shutter Speed | 1/50 (1/60) - 1/100000sec | |
Lens | 3.6mm Fix Lens | |
Gamma | 0.45 | |
White Balance | Auto White Balance | |
Sync | Internal | |
Back Light Compression | Auto | |
Power Supply | DC 12V +/- 5% | |
Power Consumption | Less Than 5W | |
Gain Control | Auto Gain Control | |
S/N Ratio | More than 48db (AGC OFF) | |
Minimum Illumination | 0.0Lux / F1.2 | |
Video Output | 1.0Vp-p, 75O | |
Dimension (LxWxH) | 65x100x100mm | |
Net Weight | 120g | |
Connectors | Total 2 connctors: (1) Power Connector (2) BNC connector - compatible with DVR Card, DVR Standalone and TV | |
Operation Temperature | -10?~+50? RH95%Max | |
Quality Certifications | CE, FCC, RoHs |
