Contact SupplierWe offer Dongfeng Concrete Mixer Truck
Drive mode 6× 4
Engine Model L340 30
Type 6-cylinder in line, turbocharging and inter cooling, mechanical injection pump, bulit-in EGR
Max. Power(Kwrpm) 2502200
Max. Torque(N. Mrpm) 13501400
Displacement(ml) 8900
Type of fuel Diesel
Compression ratio (16.6± 0.5): 1
Cab D310-S1 single berth
Gearbox Model 9JS150T-B
Max. Torque(N. M) 1500
Clutch Φ 430mm diaphragm spring clutch
Frame Height× Width× Thickness(mm) 300× 90× (8+6)
Frame width 940 (front ), Frame width 810 ( rear )
Tyre Size 11.00-20
Air conditioner AC
Dimensions Overall dimension (mm) 8840× 2500× 3930
Wheel base (mm) 3650+1350
FrontRear tread(mm) 19861860
Appr. Depa. Angel (° ) 3018
Min. Ground cleanrance(mm) 250
Mass Payload(Kg) 11870
Curb weight(Kg) 13000
G. V. W(Kg) 25000.
