Contact SupplierFeatures of the Machine:
1. Electrode Force is easily adjustable.
2. Powerful DC power supply produces welds in short time, practically no sparks and no discoloration.
3. Heat impact from welding is so small that it does not change any characteristics of the battery being welded.
4. Weld spot has the same color as the welded material.
5. All welding parameters are controlled from a keypad on the front of the machine.
6. Controller LCD panel displays welding parameters making process control accurate and convenient.
Main Applications:
Battery Pack Production, Custom Battery Packs, Battery Pack Re-building, Battery Cell Tabbing Weld Alkaline, Ni-Cd, Ni-MH, Li-Ion Cell Types, etc.
The Specification List:
SPECICATIONS DPM-10K
Output Power 10KVA
Drive Style PedalPneumatic
Output Signal Opto-electric Switch
Welding Current 0-99%(Adjust)
Electrode Diameter Φ3mm
Input Power 220VAC ±10%,50Hz
Welding Power INVERTER DC
Electrode Travel Length 15mm
Max Thickness to weld Material 0.25mm
