Drill Pipe

We are offering drill pipe.
spec weight flat-end weight external diameter d wall thickness t grade upset type
lb/ft kg/m inch mm inch mm
2-3/8″ 6.65 6.27 9.33 2.375 60.3 0.280 7.11 e、x、g、s upset
2-7/8″ 10.4 9.72 14.47 2.875 73.0 0.362 9.19 e、x、g、s upset
3-1/2″ 13.3 12.32 18.34 3.500 88.9 0.368 9.35 e、x、g、s upset
3-1/2″ 15.5 14.64 21.79 3.500 88.9 0.449 11.4 e、x、g、s upset
4″ 14.0 12.95 19.27 4.000 101.6 0.330 8.38 e、x、g、s int upset
4-1/2″ 16.6 15.00 22.32 4.500 114.3 0.337 8.56 e、x、g、s int-ext upset
4-1/2″ 20.0 18.71 27.84 4.500 114.3 0.430 10.92 e、x、g、s int-ext upset
5″ 19.5 17.95 26.70 5.000 127.0 0.362 9.19 e、x、g、s int-ext upset
5″ 25.6 24.05 35.80 5.000 127.0 0.500 12.7 e、x、g、s int-ext upset
5-1/2″ 21.9 19.83 29.52 5.500 139.7 0.361 9.17 e、x、g、s int-ext upset
5-1/2″ 24.7 22.56 33.57 5.500 139.7 0.415 10.54 e、x、g、s int-ext upset
