Dropping Point Tester Of Lubricating Grease

We are offering dropping point tester of lubricating grease.
Scope of application
applied standards: gbt4929、iso2176、astmd566、ip132.
Application range: it’s applied to measure the dropping point of lubricating grease.
Function characteristics
1. With integrated design, easy operation and maintenance;
2.with pid temperature control temperature control system, temperature control and high precision, stable;
3.heating power continuously adjustable, uniform temperature within the bath, to meet the requirements of the test.
Technical parameters
1.power supply: ac 220v ± 10%, 50hz.;
2.oil bath: volume of 600 ml beaker;
3.grease cup: chrome-plated brass made inner diameter of bs9.92mm, oil dropping hole;
4.bs2.8mm cup height of 12mm.;
5.tube: with side heat resistant borosilicate glass tube, an inner diameter of bs11.1 to bs12.7mm from the bottom of 19mm.
6.thermometer: the measuring range of -5 to 300 °c, the indexing value 1 ° c;
7.heaters: tubular, power 800w;
8.the stirring motor: speed of 60 rev min.;
9.ambient temperature: -10 ~ +40 °c;
10.relative humidity: 85%;
11.total power consumption: no more than 900w.
