Duplex Stainless Steel 2205 Plate, Thickness : 0.05mm above

Heanjia Super Metals Co. Ltd has become the premier manufacturer and supplier of the Duplex stainless steel 2205 Plate is a widely utilized alloy wire having special role in various industrial applications due to its large strength and excellent resistance to corrosion. It offers extensive resistance to the local corrosion factors like intergranular, pitting and crevice corrosion.
Specifications
Plate Size thickness: above 1mm, width: 100mm-1700mm, length: 800mm-3000mm
Chemical Composition of Duplex stainless steel 2205 Plate
Type C Mn Si P S Cr Mo Ni N
2205 steel (S31803) Min - - - - - 21.0 2.5 4.5 0.08
Max 0.030 2.00 1.00 0.030 0.020 23.0 23.0 6.5 0.20
Physical Properties of Duplex stainless steel 2205 Plate
Density
Elastic Modulus Mean Co-eff of Thermal Expansion Thermal
Conductivity Specific Heat 0 -100°C
7805(kgm3) 200 (GPa) 13.7 (μmm°C) 19(Wm.K) 450( Jkg.K)
Mechanical Properties of Duplex stainless steel 2205 Plate
Tensile Strength
(MPa) min Yield Strength
0.2% Proof (MPa) min Elongation
(% in 50mm) min Hardness
620 450 25 31 (HR) or 293(HB)
Characteristics of Duplex stainless steel 2205 Plate
• Incomparable resistance to corrosion in the various corrosive media.
• Resistance to pitting and crevice corrosion.
• Resistance to chloride stress corrosion cracking at high temperatures about 150°C.
Applications of Duplex stainless steel 2205 Plate
• Oil and Gas analysis
• Marine operations
• tanks and paper equipments
