Dust Test Chamber

We are offering dust test chamber
general introduction:
dust test chamber is maily used to test control cabinet, household appliances, low voltage electric appliance, automobile, lamps and lanterns, motorcycle parts, ect outer shells. Test chamber pressure can be constant and changed, suitable for indoor low concentration dust pollution test, assessment sample in this environment of sealing and corrosion degree. The whole system is designed to be used under extreme conditions and guarantees reliable functioning and a long service life. Independent of design and condition of the test specimen a constant dust density is reached due to special high-capacity compressed air nozzles, which leads to reliable test results.
applicable testing standards:
iec- 60529, gb2423.37, gb4706, gb 4208, gb 10485, gb 7000.1, jis-d0207-f2 , gjb 150.12, din, etc
special features:
1. Inner chamber material is sus#304 stainless steel.
2. Adopt large transparent acrylic window, convenient and direct observation internal testing conditions.
3. Adopt imported touch screen programmable controller, can control dust blowing motor, dust vibration and test time.
4. Gastight chamber door, with lock device and glass observation window. There is lamp and dust brush to ensure easy observation of inner chamber.
5. With strong dust blowing device and vibrator to ensure uniformity of each blowing.
6. Large diameter strong stainless steel air hose, covered with heating device, can heat anddry the test chamber dust.
7. Imported high-precision electronic temperature humidity sensor and air speed sensor.
8.test sample differential pressure test device, can set pumping rate freely according to sample inquiry.
