DY1100 Automatic Block Machine, Brand Name : Deyi

₹ 9.10 Lakh / 100000 100000 Set

MOQ1 Set(s)
Model NumberMechanical,electric and hydraulic integration
Brand NameDeyi
Dimension4785X4965X4690mm
Conditionlarge-tonnage,automatic and hydraulic brick production line
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Company Information

Zhengzhou Deyi Heavy Machine Manufacturing Co.,Ltd.

Member Since 14 Years
Nature of Business Supplier
Year of Establishment 1996

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Number Of FlowerDY1100
Model NumberMechanical,electric and hydraulic integration
Brand NameDeyi
Conditionlarge-tonnage,automatic and hydraulic brick production line
Dimension4785X4965X4690mm
Country of OriginChina
Nominal pressure1100T
Machine Weight80T
Output5760-7200 bricks per hour
Drive power75KW(main motor)
Quantity32 bricks/time(standard bricks)
Pressure head course500mm
Specification240X115X53mm(standard brick),240X115X90mm(porous brick),390X390X190mm(hollow brick)

technology characters of dy1100 automatic multi-function hydraulic block machine(it has got 4 patents of our country, the patent number is: 200420010260.9/200420010261.3/200410010039.8/200420010115.0):
1. dy1100 automatic multi-function hydraulic block machine is our company introduction of absorption of usa and germany technology research and development a high-tech patent product.
2. dy1100 adopts 3-beam 4-column prestress force tie bar sleeve structure and optimized finite element stress analysis, enough to withstand two thousand tons of tension.
3. adopting germany siemens plc program control, human-machine interface and touch operation.
4. oil cylinder seals all adopts germany original parts, cylinder body is forged with double alloy, internal surface by grinding under heat treatment.
5. adopting built-in displacement sensor in oil cylinder, which can control brick stuffing, high pass rate, low error(error is only 1mm).
6. hydraulic pressure station is the drive source of hydraulic press. our company adopts original hydraulic pump and directional valve of germany, making hydraulic block machine can realize preprocessing, die pressing and maintaining pressing.
