Dynemech Precision Leveling Vibration Control for Testing Machines , Series DMAS-BH1

₹ 97,900 / Piece

MOQ4 pieces
FinishingPowder Coated
MaterialAluminium And Mild Steel
CertificationISO 9001:2008
Brand NameDynemech
Supply TypeManufacturer, Exporter, Supplier, Trader
Preferred Buyer Location All over the world

Company Information

4.5/5

Member Since 21 Years
Nature of Business Manufacturer
GST No. 06AABCD4754E1ZX

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Country of OriginIndia
Total Carbohydrate1 Year,1
Working Temperature(-20°C To +70°C)
Number Of FlowerAir Spring,Membrane Air Spring Series DMAS-BH1
CertificationISO 9001:2008
UsageIndustrial
ConditionNew
FinishingPowder Coated
MaterialAluminium And Mild Steel
Brand NameDynemech

Dynemech DMAS-BH1 system consists of three master pneumatic isolators for 3-point precision levelling. Each pneumatic damping isolator consists of a self-levelling plunger mechanism. Which is the load sensing, and heigh-controlling element. The system is supplied with pressure regulator, distributor, Clean dry air is required to be supplied to the system. The DMAS-BH1 is lightweight aluminium body. The inner chamber is split into two parts i.e. load volume and damping volume. damping up to 20% can be adjusted using external valve manually. A thin reinforced elastomeric diaphragm supports the load. A safety valve protects diaphragm from over inflation. The final precise levelling of the system can be done using levelling nut provided on the plunger mechanism.

Note- GST and Freight Charges are not included.
