Ecopro Flat Cement Sheets

Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

Our Ecopro Flat Cement Sheets serve as the best and economical alternative to the traditional water proof plywood. These durable and workable Ecopro Flat Cement Sheets are made from cellulose fiber....

View More Details

Send Enquiry

Product Details

Our Ecopro Flat Cement Sheets serve as the best and economical alternative to the traditional water proof plywood. These durable and workable Ecopro Flat Cement Sheets are made from cellulose fiber and inorganic binders of silica base making them an eco-friendly option. Their thickness is cured at high temperatures and pressures that offer them dimensional stability. These sheets are also resistant to fire, water and termites which make them a feasible option. As a good insulator, they can be used to save the energy and maintain the temperature.
Dimensions

Standard Size (mm) - 3050 X 1220, 2440 x 1220, 1830 x 1220, 1220 x 1220
Standard Size (Feet) - 10' X 4’, 8' x 4’, 6' x 4’, 4' x 4'
Thickness - 5mm, 6mm, 8 mm, 9 mm, 10 mm, 12 mm, 14 mm, 16 mm, 18 mm.

Technical Specifications

Properties	Values
Standard Weight (For 6 mm)	8.25 Kg/m²
Free Moisture at EMC	10%
Swelling in water (2 hrs. soaking ) Change in thickness	0.6%
Apparent Density	> 1250 Kg /m³
Minimum Modulus of ruptrure at EMC	> 10.5 Mpa, N/mm²
Rupture (MOR) IN WET condition	> 7.0 Mpa, N/mm²
Impact Strength at EMC	1.125 Kg/mtr/sec.
Screw withdrawal strength(Face)	2200 N
Water Absorption	< 40%
Thermal Conducitivity at 50^oC Mean Temperature	0.21 W/M .k
Co-efficient of Linear Expansion	7.5 x 10-6 mm/deg C
pH value(72 hrs.)	alkaline(11 -12)
Acoustic Insulation	26 db (6mm Ecopro board) 35 db with 50 mm mineral wool. 44 db with 100 mm mineral wool.
