Contact SupplierWe are offering Electric Forklift Truck Fn1025.
Features1. Our electric counterbalanced forklift is of small size and compact structure, which greatly improves its operational flexibility 2. Curtis electrical control system from america for good reliability 3. Winner hydraulic pump station for powerful performance 4. High capacity traction battery (300ah) to ensure sufficient electricity for a day's work5. High quality solid tire provides good buffer action 6. Equipped with intelligent charger to effectively prolong the life time of battery7. Applicable to operations in restricted spaces8. Forged adjustable fork is suitable for pallets of various sizes technical specifications for electric counterbalanced forklift
model no. unit fn1025 fn1030
rated capacity kg 1000
load center mm 400
max. Fork height 2500 3000
max. Machine height 3150 3750
fork size 800
fork width 200-610(adjustable)
height of overhead guard(cabin) 1970
min. Turning radius 1440
max. Speed with load km/h 4.9
max. Speed without load 6.0/
driving motor kw 2.0
lifting motor 2.0
battery ah/v 300/24
battery weight kg 275
overall length  2376
overall width 932
overall height 1860 2210
overall net weight kg 1465.
