Electric Hoist

Electric Wire Rope Hoist:
the Wire Rope Electric Hoist Model as is Designed in Pursuance of the Standards of Din15018 and Din15020/fem and Adopted the New Technology, New Materials and Advanced Inspection Equipment, So It Has Reached the Advanced Technology Level of International. the Electric Hoist Has Manifold Lifting Capacities, Lifting Heights and the Single/double Speed Function of Lifting and Traversing. It Can also Be Matched with Traversing Trolleys Various in Kind.
the Electric Hoist of as Series Can Be Used in Conjunction with other Metallic Structure and Electric Drive or Manual Drive Single Beam Crane, Double Girder Crane, Suspension Crane, Gantry Crane.
basic Performance and Application
1. the as Electric Hoist is Designed and Manufactured According as Din15020/fem
2.
a) Lifting Capacity: 320-50000kg
b) Traversing Speed: 0.25-24m/min Has Single/double Speed Function(the Ratio of Single/double Speed is 1: 6 and 1: 10)
c) Lifting Height: 3.5-120m
d) Traversing Speed: 8-40m/min with Single/double Speed Function(the Single/double Speed Ration is 1: 4)
e) Classification Group of Mechanism; 4bm, 1am, 2m, 3m(equal to M3, M4, M5, M6)
f) Protection Class: Ip54
g) Standard Power Supply: 3ph, 50hz, 380v, Control Voltage 42v(has other Nonstandard Power Supply)
3. this Product is General-purpose Electric Hoist Suitable for Using in Work Sites of Mechanical Working Assembly and Warehouse with Ambient Temperature -25~+40c, It Can Not Be Used in Work Sites with the Danger of Explosion, the Fire Hazard Corrosion Gas and the Relative Humidity Over 85%(25 C ). It Can also Not Be Used for Hoisting Poisonous, Inflammable and Explosive Substances.
