| Model | TMPLT 10 | TMPLT 20 | TMPLT 30 | TMPLT 40 | TMPLT 50 |
Capacity ( Kg) | 1000 | 2000 | 3000 | 4000 | 5000 |
Size Of Platform ( L x W ) | 1400 x 1000 | 2180 x 1350 | 2400 x 1350 | 2240 x 1400 | 2500 x 1400 |
Min. Height (mm) | 560 | 700 | 820 | 820 | 720 |
Overall Size ( L x W ) | 2400 x 1000 | 3540 x 1350 | 3695 x 1350 | 3540 x 1400 | 3820 x 1400 |
Front Wheel Dia (mm) | 835 | 1060 | 1070 | 1070 | 1070 |
Rear Wheel Dia (mm) | 850 | 1085 | 1115 | 1115 | 1115 |
Wheel Base ( mm ) | 1135 | 1800 | 1900 | 1900 | 2185 |
Ground Clearance (mm) | 100 | 120 | 140 | 140 | 120 |
Drive speed without load (Km/h) | 10 | 12 | 12 | 18 | 18 |
Drive speed with load(Km/h) | 8 | 10 | 10 | 15 | 11.5 |
Min. Turning Radius (mm) | 3000 | 4000 | 4500 | 3900 | 4100 |
Parking Brake Distance (M) | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 |
Max. Gradeability (% x m) | 5 x 12 | 5 x 12 | 5 x 12 | 5 x 12 | 5 x 12 |
Driving Motor ( KW ) | 1.35 | 2.5 | 5 | 5 | 6.3 |
Driving Motor Rated Current (A) | 78 | 78 | 139 | 139 | 173 |
Battery Voltage ( V ) | 24 | 40 | 48 | 48 | 48 |
Battery Capacity (AH/5hr) | 250 | 250 | 308 | 330 | 440 |
