Electric Wire Rope Hoist, Material : Mild Steel

Bhagirath Heavy Transmission manufactures an exhaustive line of electric wire rope hoistsas per the customer specifications. Our products are designed and manufactured in varied capacity ranges and can be customised as per your technical specifications.

Our products are embedded with the following distinguished features:
High Performance Efficiency

• The products are designed with high-speed efficiency to add to the overall productivity levels.
• Minimum losses through precision in workmanship for all manufactured components.

Operational levels

• Ensured levels of smooth work operations by gears having precision machine cut teeth with scope for heat treatment.
• Hoists Products are provided with anti-frictional bearings on all high-speed rotating parts.
• Limit gauge checking for all machine components.

Easy Maintenance

• Easy accessibility of all the hoist parts requiring maintenance
• Inclusion of the minimum number of parts having maintenance requirement.
• Easy replacement of wearing parts for reduction in downtime.
• Rigid Inspection
• All stages of manufacture have scope for stern inspection to ensure unfailing dependability.

Types of Electric Wire rope Hoist provided by us are :

• Electric Wire rope hoist.
• Hoist for Curvature beams.
• Chain hoists.
• Flameproof hoist.
• High lift hoist.
• Electric crab hoist for double girder cranes.
• Customised hoist as per the customer specifications.

Streamlined benefits of using BHT electrical wire rope hoist are :

• High quality IS-3938 standard design for class II.
• Assembled line of hoist from independent units that are hoisting gear box, hoisting motor with brake, rope drum, electric control panel and travelling trolley.
• Easy accessibility, reduced downtime and low maintenance cost.
• Our products have fastened M.S plates with number studs to withstand the load from different independent units attached to the product.
• Compliance with Indian standard 2266 for hosting rope with factor of safety on nominal breaking strength of the rope being six.
• Grooves drum with seamless pipe of adequate length wounded in one or two layers to provide proper support with theleast scope for abrasion and wearing.
• The drum shaft is provided with self-aligned roller bearings for smooth run.
• Easy accessibility by dividing rope guide into two halves with proper drum encirclement.
• Motor are of squirrel cage with 40% CDF rating in class B insulation complying well with IS-325-1970.
• Hugewear resistance for hoist.Gearbox supported by bailer roller bearings to ensure smooth and low friction operation and well off lubrication.
• Electromagnetic safe type brake with external mounting.
• Adjustable trolley for varied I beam sizes.
• Safety feature in theform of limit switch.
• Protected steel casting rope sheaves.
• Both electric and mechanical control
• Guarantee for repair and replacement.
