Electromatic OT Table

equipped with imported electric actuators for smooth & effortless working of the table. It ensures the actuators working
in a constant speed without any noise & is designed to run even at low voltage to carry on the surgery.
Technical Constraints
Top Dimension : L 1930 XW 553 mm
Height Adiustment : 762 mm -1012 mm
Trandelenburg Reverse : 30° 25°
Lateral Tilt : 20° 20°
Kidney Elevator : 150 mm
Back Rest (up Down) : 80° 25°
Leg Rest (up Down) : 15° 90°
Head Rest (up Down) : 20° 60°
Power Supply : 24v Dc
Battery Backup (Optional) : 2-3 Hours
Key Structure
- The table has been made from acid proof, stainless steel (the face of the table is easy to clean and immune to disinfection agents)
Strong & rust free base of stainless steel is provided to make the working conditions pleasant for the doctors & nurses.
- Orthopedic attachment (hips and legs support) including the patient's pelvis support and legs support enables the limbs strain performing. Design of the Orthopedic attachment & eccentric column provides monitoring of the limbs with the C-ARM during the operation.
- The various positions such as Up-Down movements, Trendelenburg Reverse Trendelenburg, Lateral Tilts, Flex- Reflex, Chair Position as realized by remote control.
- Leg section & head section are interchangeable.
