| 技术要求 Specifications | ||||
| Rated voltage | 230VAC，250VAC，280VAC，400VAC，415VAC，430VAC，440VAC，450VAC，480VAC，525VAC，690VAC，730VAC，750VAC，1000VAC | |||
| Rated frequency | 50/60Hz | |||
| Capacitance Range | 1~100Kvar | |||
| Class of safety protection | S2 | |||
| Operating temperature range | -25℃~+55℃ | |||
| Capacitance Tolerance | -5%~ +10% | |||
| Volatge Proof | Between Teminals | 2.15Un（10S） | ||
Between terminals And Case | 3500VAC（10S） | |||
| Maximum permissible voltage | 1.1Un | |||
| Maximum permissible current | 1.3In | |||
| Insulation Resistance(IRxC) | ≥3000S（20℃，100V，1min) | |||
| Dissipation Factor | ＜0.25W/Kvar | |||
