Contact Supplierspecifications
1.working frequency:
wcdma/umts/hsdpa/hsupa: 850/900/1900/2100mhz,7.2mbps/5.76mbps
gsm/gprs/edge : 850/900/1800/1900mhz
evdo : 800/1900mhz,release a,3.1mbps/1.8mbps
hsdpa : 2100mhz,up to 2.8mbps,gsm/gprs/edge 900/1800mhz
wlan: ieee802.11b/g/n ,speed up to 150mbps(upgrade to 300mbps in the future)
2.ports:
internet settings:wan(configure parameters automatically according to relative
networks),lan,dhcp clients,advanced routing,qos
wireless settings: basic settings,advanced settings,security settings,wds,station
list
firewall: mac/ip/port filtering,port forwarding,dmz,system security,content filtering
interface: one power switch button,one reset button,one mini usb port(to charge the
battery),one sim card slot
3.power consumption:
indicator: one power status led,one charge status led,one wifi network status
led,one 3g network status led
power supply: lithium battery (1500ma)
4.dimension and weight
dimension: 94mm×54mm×13mm
weight: about 100g
temperature: work temperature -10°c ~ +55°c ,
storage temperature -20°c ~ +70°c
humidity: 5% ~ 95%
