Product Details
Company Details

Solid/Stranded (ATC/ABC) Copper conductor, insulated with specially formulated PVC/TPE/XLPE to form a core. Cores laid up together or twisted to form a pair/triad depending upon the individual requirement. Such cores/pairs/triads after laying are coated with special Fire Resistant materials and overall sheathed with special PVC/TPE/LSZH. Shielding with Braiding/Aluminium mylar taping will be done overall or individually depending upon the requirement. Armouring provided depending upon requirement with a extruded inner special PVC/TPE sheath, and overall sheath of special PVC/TPE.

Application :
To maintain circuit integrity during and after Fire

Identification :
Shall be as per cable type Control/Instrumentation Signal/Thermocouple Extn./Compensating as per their respective features list. Other combinations of colour, numerals and alphabet coding will be provided as per customer satisfaction/requirement

Standard Specification :
ICE 331/ BS 6387, IEC 60331, BS 6387 - CAT A,B,C,W,Z BS 7846 - CAT F1, F2, F3

Characteristics :
Will withstand Flame temperature of 750 degree centigrade upto 3 hours without electrical breakdown at rated voltage. Does not produce noxious smoke & fumes which hinder fire fighting and endanger life. Does not propagate flame. Special properties: Zero Halogen Low Smoke insulation & sheath material supplied on request.

Delivery Lengths :
500/1000 meters. Other lengths are upon request. Wound on wooden drums of suitable size as per factory specification. Cable ends sealed by means of a non-hygroscopic sealing material. Custom packing and drums are also available on request.

Special Properties :
Zero Halogen Low Smoke insulation & sheath material supplied on request
