Flat Die Wood Pellet Mill

We are offering flat die wood pellet mill.
Specifications
flat die wood pellet mill
new generation energy saving machine 2. Raw material size should be less than 5mm
raw material moisture should be 10-20%4.have ce certificate.
flat die wood pellet mill description:
flat die wood pellet mill is a new generation of energy-saving products, researched and developed by our researcher. It is mainly used to compress crushed sawdust, straw, cotton stalk, rice husk, peanut shell, bamboo powder and wood chips etc. Into cylindrical and square shape particles.
flat die wood pellet making machine can make pellet of 6mm,8mm,10mm, etc.electric motor and diesel engine as your requirement .
1. Flat die pellet mill can make all kinds of solid grain to be small pellet feed for animals like fish, shrimps, chicken, rabbit, horses, goats, etc, or you can make bedding pellets for animal stalls from cardboard. It can also make all kinds of saw dust, paddy straw, sunflower stalk, forestry wastes, wood chips and many other wastes into wood pellets to be used as fuels.
2. The utility model is especially suitable for feeders, farmers as a processing machine of grains and feedings.
3. This series of feed particle machine is a small device, it is designed for rural breeding, specialized households, small and medium-sized feed mill, livestock farm, and it can process a variety of feed
pellets of different diameters.
4. Machine critical components using special materials and special processing, such as pressure rollers use a vacuum furnace imports from germany for surface hardening, and powerful shot peening, surface hardness up to hrc62 good wear resistance, long life, mold plate the special design principle, uniform and reasonable layout of the die hole, after surface hardening and shot peening, good wear resistance, and high-capacity, uniform material, long life.
flat die wood pellet mill main technical date
model capacity(kgh) power n.w.g.w. (kg) overall dimension (mm)
azsp120a 75-100 6-8hp 120 140 900×440×730
azsp120b 75-100 2.2-3kw 80 100 710×390×910
azsp150a 100-150 8-12hp 180 220 870×440×700
azsp150b 90-120 4kw 95 115 750×350×650
azsp200a 250-300 15-18hp 210 240 1000×460×900
azsp200b 200-300 7.5kw, 200 230 1000×430×950
azsp230a 300-400 22-24hp 280 310 1180×560×1020
azsp230b 300-400 11kw 290 320 1140×470×970
if you have any questions, don't hesitate to contact me. We will give you some good suggestions. And the above technical data of azs150 pellet machine is just for your reference. If they can’t meet your needs, we also have other types for you.
