Flat Dripper Mould With Semi Hot Runner

we are ofering flat dripper mould with semi hot runner 1.model number: cy-sh-f64
2.runner style:semi hot runner
3.products from mould: inline round drippers
4.cavity quantity: 64
5.overall dimension: 450mm×500mm×460mm
6. designing weight: 650kg
7. injection molding machine: clamping force over 210t
8. cycle time :12s to 15s
9.service life :over 1 million shots
10. spre style: pinpoint gate
11. flow rate deviation :≤5%
12.cooling method:by circulating water
13.mould base :lkm （4050ci a90 b160）
14. cavity material: s136（assab）
15. core material: skd61（japan daido）
16. loose core: cylinder slider structure
17.nozzle diameter: ￠16
18. cooling water nozzle: m10 （brass）
19. backhaul spring:￠50×100
20.holding ring: ￠100mm
