ApplicationGas Fitting, Oil Fitting, Water Fitting
Size1.1/2inch, 1inch,50MM
CertificationISO 9001:2008 Certified
FeatureDurable
PatternPlain
Number Of FlowerFloat Ball Valve
StructureBALL
Country of OriginIndia
Number Of Way2way
Working principle The float always needs to float on the water, and when the water rises, the float also rises. When the float rises, it drives the connecting rod to also rise. The connecting rod is connected to the valve at the other end, and when it rises to a certain position, the connecting rod supports a rubber piston pad to seal off the water source. When the water level drops, the float also drops, and the connecting rod drives the piston pad to open. Float valves regulate the liquid supply by controlling the liquid level. A full liquid evaporator requires the liquid level to maintain a certain height, and it is generally suitable to use a floating ball expansion valve. The working principle of a float valve is to control the opening or closing of a valve by lowering and raising the float ball in the float chamber under the action of the liquid level. The floating ball chamber is placed on one side of the full liquid evaporator, and the upper and lower parts are connected to the evaporator through a balance tube, so the liquid level height of the two is the same. When the liquid level in the evaporator drops, the liquid level in the floating ball chamber also drops, so the floating ball drops and relies on the lever to increase the valve opening and increase the liquid supply. vice versa. Feature & Design 1. The valve is equipped with open and close position indicators; 2. Locking device; 3. Valve stem anti flying structure; 4. Anti static device; 5. Fire resistant structure; 6. Unique valve seat sealing structure; 7. no external leakage structure. Advantages & Feature\\\
Easy maintenance
\\\
Flexible and durable
\\\
High accuracy of liquid level control
\\\
The water level is not affected by water pressure and has the characteristics of tight opening and closing without water leakage
\\\
\\\
Additional Information
Payment Terms L/C, T/TWestern Union
Port of DispatchANY
Packaging DetailsTo better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided. Float ball valves are suitable for industries such as food, chemical, petroleum, natural gas, and metallurgy, as well as natural gas long-distance pipelines containing hydrogen sulfide, impurities, and severe corrosion.
Delivery Time10 DAYS
