Flood Light

Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

Features Complete Isolated Driver Highly efficient constant current LED drivers Fast start-up time Short circuit & open circuit protection on driver O/p over voltage available Short circuit....

View More Details

Send Enquiry

Company Information

Notion electronics

Memco, Ahmedabad, Gujarat

View Number

Member Since 8 Years
Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

Features

Complete Isolated Driver
Highly efficient constant current LED drivers
Fast start-up time
Short circuit & open circuit protection on driver
O/p over voltage available
Short circuit available
Thermal cutoff available
High brightness power LED?s
No Glare, No Flash
No UV or IR radiation
Aesthetically designed aluminium extruded /die-cast enclosures
Optimized heat sink design for excellent thermal management
Extremely cost effective operation
Green & Environment Protection

Applications

Highways
Streets
Residential colonies
Ware houses
Petrol pump
Parking lots
Public Walkways
Pathway Lighting
Roadway Lighting
Public squares & Parks
Industries & Institutional Campuses

Product Code:	NEFL20W
Power Consumption:	20 W
Input Voltage Range:	90-270V AC
Operating Supply Frequency:	50 Hertz to 60 Hertz
Surge Protection:	4KVA
Power Factor:	> 0.9
THD:	<10%
Driver Efficiency :	> 85%
LED Beam View Angle:	120 Degree
Color Rendering Index:	>80
LED LM-80 Report:	Yes
LED Lumen Output	130 lm/W
Standard Colors	Cool White, Warm White, Neutral White, Others
Body Type:	Aluminum Pressure Die Cast
IP Protection Standard:	IP65 Standard
Covering:	Toughened Glass
Dimension:	132 (W) x 95 (L) x 80 (D) mm
