Floor-mounted Door Closer

Universal floor-mounted closer for use with fire and smoke doors

The floor-mounted closer TS 550 NV F was developed specifically for aesthetically inconspicuous use on heavy fire and smoke doors and can bear maximum leaf weights of up to 300 kg. Due to the minimal installation height of just 54 mm easy mounting on existing installations is also possible.

Product features

• Floor-mounted closer TS 550 NV F for leaf widths up to 1400 mm and high leaf weights of up to 300 kg
• For use with fire and smoke doors
• Closing force infinitely variable EN 3-6 – an advantage with wind loads or heavy door leaves
• Fixed opening damping
• End stop and closing speed adjustable
• Flexibly adjustable closing speed for 180°-80° with two functions
• Open: Closing speed 180°-80°
• Almost closed: Closing delay
• All settings accessible from above and convenient to implement whilst installed
• Durability tested in over 500,000 opening and closing cycles
