| Model | 15 Kg | 30 Kg | 60 Kg | 120 Kg | 200 Kg | 300 Kg |
|---|---|---|---|---|---|---|
| Container Volume LTRS | 46 | 71 | 142 | 288 | 475 | 650 |
| Batch Size Min. & Max. | 10 to 15 | 20 to 30 | 40 to 60 | 80 to 120 | 160 to 200 | 200 to 300 |
| Blower Motor HP | 5 | 5 | 10 | 20 | 25 | 30 |
| Air Flow CFM | 429 | 706 | 1059 | 1882 | 2588 | 3235 |
| Steam Consumption (kg/hour) | 36 | 50 | 72 | 144 | 216 | 250 |
| Steam Pressure (kg/cm sq.) | - | - | - | 3.5 | - | - |
| Electric Heater (Kw) | 20 | 20 | 36 | - | - | - |
| Compressed Air Pressure Bar | 6 Bar | 6 Bar | 6 Bar | 6 Bar | 6 Bar | 6 Bar |
| Drying Temprature | 35'C-80'C | 35'C-80'C | 35'C-80'C | 35'C-80'C | 35'C-80'C | 35'C-80'C |
| Electrical Supply | 3 Phase 415 Volts | 3 Phase 415 Volts | 3 Phase 415 Volts | 3 Phase 415 Volts | 3 Phase 415 Volts | 3 Phase 415 Volts |
