Contact SupplierTravel method x & y � axis beam move
drive method x rack & pinion � y & z ball screw
work area x = 121" (3070mm), y = 61" (1550mm),
z = 7.87" (200mm)
maximum thickness â��" mild steel, â½" stainless steel, â��" aluminum
maximum work weight
2,000 lbs.
Rapid traverse x, y = 3,150"min. Simultaneous = 4,455"min.
Z = 2,362"min.
Repeatability +0.0002"
z-axis sensor hs-2000
os:fanuc 160i-l
assist gas control automatic select
oscillator af4000ib � 4000 watt
approximate machine weight 34,216 lbs. (includes shuttle table)
power requirements
200220v â±10% 5060hz
control function x, y, z-axis simultaneous and focus lens b-axis, adaptive optic and laser power control (cw, gated pulse, pierce routines etc.)
minimum command unit 0.0001" (x, y, z)
minimum travel unit 0.0001" (x, y, z)
year:2007
