| MODEL | SA-06-AFFF | SA-09-AFFF | SA-09-AFFF(C) |
|---|---|---|---|
| Capacity | 6 LTR | 9 LTR | 9 LTR |
| Confirming IS Code | 15683 | 15683 | 15683 |
| Type of Extinguishers | Stored Pressure | Co2 Gas Cartridge Type | |
| Type of Extinguisher Media | Soft Water | ||
| Expellant | Pressurized with Nitrogen(N2) Gas | - | |
| Diameter (Approx) | 150 ± 10 mm | 175 ± 10 mm | 175 ± 10 mm |
| Height (Approx) | 500 mm | 550 mm | 560 mm |
| Filled Weight (Approx) | 9.0 kg | 12.5 kg | 14.0 kg |
| Empty Weight (Approx) | 3.0 kg | 3.5 kg | 5.0 kg |
| Average Discharge Time | 20 sec. | 40 sec. | 40 sec. |
| Operating Temperature | -5°C to 60°C | ||
| Working Pressure at 20°C | 15.5 bar | ||
| Maximum Service Pressure | 17.5 bar | ||
| Hydraulic Test Pressure | 35.0 bar | ||
| Fire Rating | 2A 21B | 4A 144B | 4A 144B |
| Approvals | BIS & CE | BIS & CE | BIS & CE |
