DIMENSIONS (L XWX H)- WITHOUT RAMP FOR SQUEARE TUBE7000 X 3500 X 3200 (MM)
WASH CAPACITY20 CARS/HR
WATER PRESSURE20-22 BAR AT PUMP DELIVERY
DIMENSIONS (L X W X H )-WITHOUT RAMP FOR STANDARD TYPE7000 X 3800 X 3500 (MM)
Benefits
Reduces Time, Efforts & Manpower & Cost.
Easy to operate.
High quality wash.
Uses high pressure water technology.
Pre-installation Requirements
3 Phase electric supply (4Sq. mm X 4 C) : 415 V +/- 10 V, 50 Hz Up to our control panel.
63 Amp, 4 Pole MCB just before the control panel.
Overhead water tank from ground level to 15ft height . The min. size of water tank should be 3000 Ltrs. Pipeline from Overhead tank to inlet of Pump should be 2″.
6 bar compressed air connection upto our control panel.
Y Shape Strainer in the inlet line before our pump (Y-Strainer size- 1 ¼” ).
Covering / Shed for the entire system(Including pump & Panel, Shed Height- Above 5 Mtr. from ground level to top).
Incoming Cable 4 Sq. mm X 4 Core + Earthing.
PCC -6″ (150 mm –Thickness).
Clear floor area for installation & Underbody pit.
We needed Proper drainage line.
FRL Unit in pneumatic inlet line.
