Full Automatic Scale Screen Printing Machine

We are offering full automatic scale screen printing machine.
Application
plastic ruler screen printing machine is special designed for printing stationery ruler with high speed and automatic. Building up printing and conveying system by high precision servo motor and cam divider to finish printing automatically, reduce labor, improving efficiency. The printing speed can be up to 2000pcshr, suitable for printing rulers within 30cm.
Features
1. Fully automatic, no need person to operate
2. Locating automatically to keep printing precision
3. No product without printing system, keep printing stable
4. High and strong vacuum system, keep printing precision
5. Uv dryer or high temperatu
6. Mitsubishi plc (japan) with weinview (taiwan) touching screen control system. Digital control system, can set parameter randomly, operate easily with big function
7. The four angle of screen frame holder can be adjusted, keep the balance between screen frame and worktable, also make sure the layer of printing ink is even
8. Printing angle, printing pressure and screen distance are easy to set. The change of squeegee and flood bar is controlled by precision guide, keeping the vertical precision, working smoothly
9. With emergency switch to keep safe and stable
10. Locating several workstations by taiwan precision rotary locating with stable, fast, improving efficiency
technical parameter
max.printing area:200*300mm
max.printing speed:2500pcshr
worktable size:250*450mm
max.frame size:300*500mm
left and right stroke:350mm
up and down stroke:100mm
disc size: 600mm
workpiece max.height: 50mm
power:220v 50-60hz
machine size: 2400*1200*1470mm
weight:560kg
