ApplicationSpesific audio effects for entry/exit and different body color optional.
Length of Arm65 cm standard
ControlSuitable for using through direct PC control together with dry contact to trigger or 3-50V DC impact, TTL, CMOS, or RS232/422/485. Easily connected to any access contol units and other peripheral units.
ApplicationSpesific audio effects for entry/exit and different body color optional.
Technical ServiceFast and uninterrupted high-quality, expert technical support throughout Turkey, Turkish Republic of Northern Cyprus, Central Asia and Balkans.
ExtrasDifferent voltage support is available. Suitable solutions can be realized depending on the needs.
Warranty2 years
Display PanelsLigthing indicator with three positions ensures passing control of the system. If the turnstile is ready for passing a green arrow blinks. When passing is allowed green arrow lights permanent. At the moment of passing through, a red 'X' lights up indicati
Emergency ModePossible to control through connection with security systems. (Automatic free passing-panic mode in case of emergency, fire alarm )
Power Consumption60 Watt
Quality StandardsTSEK, ISO 9001:2008
Operational Temparature(-20), (+60) C
SystemMicro-processor controlled system. Operates in two directions. Allows passing in one direction. A data output is available in the direction advanced. This may either be a digital output to additional equipment or may be sent directly to a PC. System switc
Special DesignThanks to its special design, offers a decorative aspect as well as a soft, easy and silent access.
Power Input100 - 240 V AC
ControlSuitable for using through direct PC control together with dry contact to trigger or 3-50V DC impact, TTL, CMOS, or RS232/422/485. Easily connected to any access contol units and other peripheral units.
Dimensions1530 x 1560 x 2300 mm
Length of Arm65 cm standard
Body1,5 mm 304 quality stainless steel or electrostatic paint on metal sheet
